| Main Features： | |
 Qualcomm Eight Core Chip |  5.5-inch screen |
 6000mAh battery |  IP 65 1.5-meter drop test |
 WiFi/4G/Bluetooth |  CE certification, FCC |
| function： | |
 UHF RFID |  QR code |
 Fingerprint |
| Model No. | VH-H78 |
| PHYSICAL CHARACTERISTICS | |
| Dimension | 166mm(H)x79mm(W)x27mm(D)±2 mm |
| Weight | Net Weight:400g (including battery&wrist strap) |
| Display | Tough 5.5 in. TFT-LCD(720x1440)touch screen with backlight |
| Backlight | LED backlight |
| Expansions | 1 PSAM, 1 SIM, 1 TF |
| Battery | Rechargeable li-ion polymer, 3.8V, 4800mAh |
| PERFORMANCE CHARACTERSTICS | |
| CPU | Cortex A73 2.0GHz octa-core |
| Operating System | Android 10.0 |
| Storage | 2GB RAM/16GB ROM or 4GB RAM/64GB ROM, MicroSD(max 256GB expansion) |
| USER ENVIRONMENT | |
| Operating Temp | -20℃ to 50℃ |
| Storage Temp | -20℃ to 70℃ |
| Humidity | 5%RH to 95%RH(non-condensing) |
| Drop Specifications | 5ft./1.5 m drop to concrete across the operating temperature range |
| Sealing | IP65, IEC compliance |
| ESD | ±15kv air discharge, ±8kv direct discharge |
| DEVELOPMENT ENVIRONMENT | |
| SDK | VANCH Demo Software Development Kit |
| Language | Java |
| Environment | Android Studio or Eclipse |
| DATA COMMUNICATION | |
| WWAN | TDD-LTE Band 38, 39, 40, 41; FDD-LTE, Band 1, 2, 3, 4, 5, 7, 8, 12, 17, 20;WCDMA (850/1900/2100MHz);GSM/GPRS/Edge (850/900/1800/1900MHz); |
| WLAN | 2.4GHz/5.0GHz Dual Frequency, IEEE 802.11 a/b/g/n/ac |
| WPAN | Bluetooth Class v2.1+EDR, Bluetooth v3.0+HS, Bluetooth v4.2 |
| GPS | GPS(embedded A-GPS), accuracy of 5 m |
| ACCESSORIES | |
| Standard | 1xPower Supply;1xLithium Polymer Battery; 1xType-C cable |
| Optional | Cradle |
| BARCODE READER(OPTIONAL) | |
| 2D Barcode | 2D CMOS Imager Zebra Se4710 |
| Symbologies PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR code, Micro QR code, Aztec, MaxiCode, Postal Codes, US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal, Dutch Postal. etc. | |
| COLOR CAMERA | |
| Resolution | Rear 13 megapixel, front 5.0 megapixel |
| Lens | Auto-focus with LED flash Auto-focus with LED flash |
| RFID READER(OPTIONAL) | |
| RFID LF | Frequency 125KHz/134.2KHz(FDX-B/HDX) |
| Protocol ISO 11784&11785 | |
| R/W Range 2cm to 5cm | |
| RFID HF/NFC | Frequency 13.56MHz |
| Protocol ISO 14443A&15693 | |
| R/W Range 2cm to 8cm | |
| RFID UHF | Frequency 865~868MHz or 920~925MHz |
| Protocol EPC C1 GEN2/ISO 18000-6C | |
| Antenna Gain Circular antenna(2dBi) | |
| R/W Range 1.5 m to 2 m(tags and environment dependent) | |
| FINGERPRINT READER(OPTIONAL) | |
| Sensor | TCS1xx |
| Sensor type | Capacitive, area sensor |
| Resolution | 508 DPI |
| Performance | FRR<0.008%, FAR<0.005% |
| Capacity | 1000 |
| PSAM SECURITY(OPTIONAL) | |
| Protocol | ISO 7816 |
| Baudrate | 9600, 19200, 38400, 43000, 56000, 57600, 115200 |
| Slot | 2 slots(maximum) |
